TUBE     OD

NPT
SIZE

BASIC
ORDERING
NUMBER

ALL DIMENSIONS IN MM
(Fractional)

A

B

C

1/8

1/4

CEI-02-ME-2IT-F

20.50

24.50

15.0

3/16

1/8
1/4

CEI-03-ME-2IT-F
CEI-03-ME-2IT-F

20.50
20.50

22.0
24.50

15.0
24.50

1/4

1/8
1/4
3/8
1/2

CEI-04-ME-2IT-F
CEI-04-ME-4IT-F
CEI-04-ME-6IT-F
CEI-04-ME-8IT-F

20.50
20.50
25.0
24.0

22.0
24.50
29.0
33.0

15.0
15.0
20.0
22.0

3/8

1/8
1/4
3/8
1/2

CEI-06-ME-2IT-F
CEI-06-ME-4IT-F
CEI-06-ME-6IT-F
CEI-06-ME-8IT-F

26.0
25.50
25.50
25.90

25.0
28.50
28.50
34.0

20.0
20.0
20.0
22.0

  1/2

1/8
1/4
3/8
1/2

CEI-08-ME-2IT-F
CEI-08-ME-4IT-F
CEI-08-ME-6IT-F
CEI-08-ME-8IT-F

25.90
25.90
25.90
25.90

28.20
28.20
28.20
34.0

20.0
20.0
20.0
22.0

5/8

1/2

CEI-10-ME-8IT-F

30.50

37.50

27.0

3/4

1/2
3/4

CEI-08-ME-8IT-F
CEI-12-UE-12IT-F

30.60
30.60

36.80
36.80

27.0
27.0

1

1/2
3/4
1

CEI-16-ME-8IT-F
CEI-16-ME-12IT-F
CEI-16-ME-16IT-F

36.80
37.20
37.20

41.60
46.0
47.20

36.0
36.0
36.0

    1 ½

1
1 1/4

CEI-24-ME-16IT-F
CEI-24-ME-20IT-F

37.20
50.80

47.20
46.50

36.0
55.0

TUBE      OD

NPT
SIZE

BASIC
ORDERING
NUMBER

ALL DIMENSIONS IN MM

A

B

C

4

1/4

CEI-04M-ME-4IT-F

22.10

22.10

12.50

6

1/8
1/4
3/8
1/2

CEI-06M-ME-2IT-F
CEI-06M-ME-4IT-F
CEI-06M-ME-6IT-F
CEI-06M-ME-8IT-F

22.10

22.10

15.0

8

1/8
1/4
3/8
1/2

CEI-08M-ME-2IT-F
CEI-08M-ME-4IT-F
CEI-08M-ME-6IT-F
CEI-08M-ME-8IT-F

22.30

22.30

15.0

10

1/4
3/8
1/2

CEI-10M-ME-4IT-F
CEI-10M-ME-6IT-F
CEI-10M-ME-6IT-F

25.80

25.80

20.0

12

1/4
3/8
1/2

CEI-12M-ME-4IT-F
CEI-12M-ME-6IT-F
CEI-12M-ME-8IT-F

25.50

25.50

20.0

16

1/2

CEI-16M-ME-8IT-F

30.50

30.50

27.0

18

1/2
3/4

CEI-18M-ME-8IT-F
CEI-18M-ME-8IT-F

30.50
30.60

30.50
37.20

27.0
27.0
