TUBE     OD

NPT     SIZE

BASIC
ORDERING
NUMBER

ALL DIMENSIONS IN INCHES(Fractional)

D

LY

F

1/8

1/8

CEI-02-FRT-02N-F

0.50

0.75

9/16

3/16

1/8

CEI-03-FRT-02N-F

0.54

0.75

9/16

1/4

1/8
1/4

CEI-04-FRT-02N-F
CEI-04-FRT-04N-F

0.60
0.60

0.75
0.88

9/16
3/4

5/16

1/8

CEI-05-FRT-02N-F

0.64

0.75

5/8

   3/8

1/4

CEI-06-FRT-04N-F

0.66

0.88

3/4

1/2

1/4
3/8
1/2

CEI-08-FRT-04N-F
CEI-08-FRT-06N-F
CEI-08-FRT-08N-F

0.90
0.90
0.90

1.13
0.88
1.12

7/8
7/8
1.1/16

5/8

1/2

CEI-10-FRT-08N-F

0.96

1.13

1.1/4

3/4

3/4

CEI-12-FRT-12N-F

0.96

1.25

1.1/4

7/8

1/2
3/4

CEI-14-FRT-08N-F
CEI-14-FRT-12N-F

1.02
1.02

1.25
1.25

1.1/4
1.1/4

1

3/4
1

CEI-06-FRT-12N-F
CEI-16-FRT-16N-F

1.23
1.23

1.25
1.50

1.3/8
1.11/16

TUBE     OD

NPT     SIZE

BASIC
ORDERING
NUMBER

ALL DIMENSIONS IN MM

D

LY

F

6

1/8
1/4

CEI-04M-FBT-02N-F
CEI-04M-FBT-04N-F

15.30
15.30

19.0
22.40

14.0
19.0

8

1/8
1/4

CEI-04M-FBT-02N-F
CEI-04M-FBT-04N-F

16.20
16.20

19.0
22.40

16.0
19.0

10

1/4

CEI-04M-FBT-04N-F

17.20

22.40

19.0

12

1/4
3/8
1/2

CEI-12M-FBT-04N-F
CEI-12M-FBT-06N-F
CEI-12M-FBT-08N-F

22.80
22.80
22.80

22.40
22.40
28.50

22.0
22.0
27.0

16

1/2

CEI-16M-FBT-08N-

24.40

28.40

27.0
