TUBE OD |
BASIC |
ALL DIMENSIONS IN INCHES(Fractional) |
||
D |
L |
F |
||
1/16 |
CEI-1-TC-F |
0.34 |
0.39 |
7/16 |
1/8 |
CEI-2-TC-F |
0.50 |
0.53 |
7/16 |
3/16 |
CEI-3-TC-F |
0.54 |
0.58 |
7/16 |
1/4 |
CEI-4-TC-F |
0.60 |
0.63 |
9/16 |
5/16 |
CEI-5-TC-F |
0.64 |
0.67 |
5/8 |
3/8 |
CEI-6-TC-F |
0.66 |
0.72 |
11/16 |
1/2 |
CEI-8-TC-F |
0.90 |
0.75 |
7/8 |
5/8 |
CEI-10-TC-F |
0.96 |
0.78 |
1 |
3/4 |
CEI-12-TC-F |
0.96 |
0.84 |
1.1/16 |
7/8 |
CEI-14-TC-F |
1.02 |
0.94 |
1.3/8 |
1 |
CEI-16-TC-F |
1.23 |
1.03 |
1.3/8 |
TUBE OD |
BASIC |
ALL DIMENSIONS IN MM |
||
D |
L |
F |
||
2M |
CEI-2M-TC-F |
12.90 |
13.50 |
11.0 |
3M |
CEI-3M-TC-F |
12.90 |
13.50 |
11.0 |
4M |
CEI-4M-TC-F |
13.70 |
14.70 |
11.0 |
6M |
CEI-6M-TC-F |
15.30 |
15.70 |
14.0 |
8M |
CEI-8M-TC-F |
16.20 |
17.0 |
16.0 |
10M |
CEI-10M-TC-F |
17.20 |
19.0 |
19.0 |
12M |
CEI-12M-TC-F |
22.80 |
19.0 |
22.0 |
14M |
CEI-14M-TC-F |
24.40 |
19.80 |
25.0 |
15M |
CEI-15M-TC-F |
24.40 |
19.80 |
25.0 |
16M |
CEI-16M-TC-F |
24.40 |
19.80 |
25.0 |
18M |
CEI-18M-TC-F |
24.40 |
21.30 |
27.0 |
20M |
CEI-20M-TC-F |
26.0 |
23.90 |
30.0 |
22M |
CEI-22M-TC-F |
26.0 |
23.90 |
30.0 |
25M |
CEI-25M-TC-F |
31.30 |
26.20 |
35.0 |
