TUBE     OD

BSPP     SIZE

BASIC
ORDERING
NUMBER

ALL DIMENSIONS IN MM
(Fractional)

A

B

C

1/4

1/4

CEI-04-FC-04IPG

29.0

10.50

19.0

3/8

CEI-04-FC-06IPG

30.50

10.50

24.0

1/2

CEI-04-FC-08IPG

35.50

10.50

27.0

5/16

1/4
1/2

CEI-05-FC-04IPG
CEI-05-FC-08IPG

30.0
36.80

11.80
11.80

19.0
27.0

3/8

1/4
3/8
1/2

CEI-06-FC-04IPG
CEI-06-FC-06IPG
CEI-06-FC-08IPG

30.0
31.80
36.80

11.80
11.80
11.80

19.0
24.0
27.0

1/2

3/8
1/2

CEI-08-FC-06IT
CEI-08-FC-08IT

32.0
37.0

12.0
12.0

24.0
27.0

TUBE     OD

BSPP     SIZE

BASIC
ORDERING
NUMBER

ALL DIMENSIONS IN MM

A

B

C

3

1/4

CEI-3M-FC-01IPG

29.30

10.80

19.0

6

1/4
3/8
1/2

CEI-6M-FC-04IPG
CEI-6M-FC-06IPG
CEI-6M-FC-08IPG

29.30
30.80
35.80

10.80
10.80
10.80

19.0
24.0
27.0

8

1/4
3/8
1/2

CEI-8M-FC-04IPG
CEI-8M-FC-06IPG
CEI-8M-FC-08IPG

30.60
32.40
37.40

12.40
12.40
12.40

19.0
24.0
27.0

10

1/4
3/8
1/2

CEI-10M-FC-04IPG
CEI-10M-FC-06IPG
CEI-10M-FC-08IPG

30.70
32.50
37.50

12.50
12.50
12.50

19.0
24.0
27.0

12

1/4
3/8
1/2

CEI-12M-FC-04IPG
CEI-12M-FC-06IPG
CEI-12M-FC-08IPG

30.70
32.50
32.50

12.50
12.50
12.50

22.0
24.0
24.0
